Wiring method for level gauge: 1 Resistance rotation type: It is necessary to carefully observe the voltage level. There are six terminals inside, two power lines, one grounding wire, and three signal lines (common line, L line, H line). 2. Capacitive level gauge: There are four terminals that need to be wired, including two power lines and two signal lines. One power line can be connected to the L or H line of the signal line. (The feeding position is connected to the public line and H line; The feeding position is connected to the public and L lines Capacitive: To determine the voltage level, our factory usually uses 24V for sending tanks. There are a total of 4 terminals inside, and the wiring diagram can be found in the instructions on the inside of the cover. Terminal 1 is a positive 24V power supply, terminal 2 is a negative 24V power supply, and terminal 3 and terminal 4 are a set of passive normally open points. According to the drawing, one of the power cords can be connected together with terminal 3 or terminal 4. If it is not possible to identify the loading and unloading positions on the same tank, just observe the model labeled on it. Generally, for S1000 tanks, the loading position is 350mm and the unloading position is 1600mm. 4. For the float ball and angled level gauges in the liquid tank, only two wires need to be connected, and for the rod type, three wires (loading line, unloading line, and common line) need to be connected
